PETRORAQ offers following CAD Services using CAD Tools (BIM, Tekla, Revit, Inventor, Advance Steel, Sketchup, CADWorx  & AutoCAD).

  • Equipment GA and Detail Drawings
  • Piping 3D Modeling
  • Piping GA & Isometric Drawings
  • Structure Modeling & Fabrication Drawings
  • Foundation Drawings Layout Plans
  • Cable Routing & Hookup Drawings
  • BIM Modeling
  • As – built drawings



BIM Model

PETRORAQ provides on BIM Modeling in REVIT. Our Services includes but not limited to:

  • Native BIM Model
  • IFC Model
  • Naviswork Model
  • Drawings
  • Schedules of Quantities
  • Visualization
  • Construction Simulation-4D
  • Clash Detection Report
  • Digital Mockup
  • COBie & Uniclass Parameters
